Precision Machining Ceramic Parts Alumina Zirconia Silicon Carbore Ceramic Spare Components for Equipments

Product Categories

Dongguan Ming Rui Ceramic Technology Co.,ltd

Contact Now

Precision Machining Ceramic Parts Alumina Zirconia Silicon Carbore Ceramic Spare Components for Equipments

Name: Precision Machining Ceramic Parts Alumina Zirconia Silicon Carbore Ceramic Spare Components for Equipments
Brand: Mingrui
Price: 1 USD

China Precision Machining Ceramic Parts Alumina Zirconia Silicon Carbore Ceramic Spare Components for Equipments wholesale

Brand Name : Mingrui

Model Number : MR-IN-0432

Certification : ISO9001

Place of Origin : China

MOQ : 5 pieces

Price : negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram, D/P, D/A

Supply Ability : 4000 pieces month

Delivery Time : 25 working days after your deposit

Packaging Details : intertional carton box

Material : Alumina Ceramic

Surface : Pulishing

Dimension : according the drawing

technology : machining

standard : International Standard

MOQ : 5PCS

warranty : 8Months

Shipping : DHL EMS UPS FEDEX TNT

Item : OEM Machining Ceramic Parts For Oil Industry Oil Tube Valve

OEM : yes

Contact Now

Precision Machining Ceramic Parts Alumina Zirconia Silicon Carbore Ceramic Spare Components for Equipments

As a ceramic parts manufacturer, us specializes in the production of zirconia ceramic precision parts,alumina ceramic precision parts,silicon nitride ceramicprecision parts,silicon carbide ceramicprecision parts,machinable ceramicprecision parts,microporous ceramicprecision parts,aluminum nitride ceramicprecision parts, Cemented carbide(tungsten steel) precision parts, etc.

Products are widely used in precision machinery manufacturing, microelectronics, semiconductor, aerospace, biomedical, fiber optic communications, testing and inspection, solar photovoltaic and other fields.

Our Ceramic Products Material Properties:

	95% Alumina	99% Alumina	Zirconia	Silicon carbide	Silicon nitride	Aluminum nitride	Machinable ceramic
Colour	white	Light yellow	white	black	black	gray	white
Density (g/cm3)	3.7g/cm3	3.9g/cm3	6.02g/cm3	3.2g/cm3	3.25g/cm3	3.2g/cm3	2.48g/cm3
Water Absorption	0 %	0 %	0 %	0 %	0 %	0 %	0 %
Hardness(HV)	23.7	23.7	16.5	33	20	-	-
Flexural Strength(MPa)	300MPa	400MPa	1100MPa	450MPa	800MPa	310MPa	91MPa
Compressive Strength(MPa)	2500MPa	2800MPa	3600MPa	2000MPa	2600MPa	-	340MPa
Young's Modulus Of Elasticity	300GPa	300GPa	320GPa	450GPa	290GPa	310~350GPa	65GPa
Poisson's Ratio	0.23	0.23	0.25	0.14	0.24	0.24	0.29
Thermal Conductivity	20W/m°C	32W/m°C	3W/m°C	50W/m°C	25W/m°C	150W/m°C	1.46W/m°C
Dielectric Strength	14KV/mm	14KV/mm	14KV/mm	14KV/mm	14KV/mm	14KV/mm	14KV/mm
Volume Resistivity(25ºC)	>1014Ω·cm	>1014Ω·cm	>1014Ω·cm	>105Ω·cm	>1014Ω·cm	>1014Ω·cm	>1014Ω·cm

This data is typical for laboratory testing and the actual characteristics of a particular production batch may vary.

Machining Accuracy

(1) Axis: roundness 0.002 mm, concentricity 0.002 mm, smoothness Ra0.1;

(2) Hole: the minimum processing hole diameter is 0.2 mm and the depth is up to 6 mm (depending on the material);

(3) Slot (seam): a minimum of 0.1 mm narrow groove, and grooves of various shapes;

(4) Plane: 0.1MM sheet with minimum processable thickness, parallelism 0.001mm, measurement tolerance 0.001 mm, finish Ra0.1;

(5) Thread: The minimum Machinable M2 internal thread, the accuracy of GB-7h, the external thread size is not limited, the accuracy is GB-6g.

Precision Machining Ceramic Parts Alumina Zirconia Silicon Carbore Ceramic Spare Components for Equipments

Delivery:
Custom OEM will be shipped within 15 days after determining the parameters
The samples will be shipped within 3 days
Quick Delivery Via Fedex,DHL,UPS,TNT Etc.
Support customer to designate shipping company
For more informations (the price,delivery time,moq etc)about the ceramic plates, please contact us or email:admin@cerampart.com

CEO: Admin deng

Dongguan Mingrui Ceramic Tech. Co. Ltd.

Add: No.21 Chuangxing Rd., 2nd Industrial Zone of Shangsha,

Chang'an town, Dongguan city, Guangdong, China 523867

Email: admin@cerampart.com

FAQ
1. Monthly Capacity: 50,000-60,000 pcs;
2. Material: OEM or as per your suggestion;
3. Lead time: about 7-20 days, pls confirm the quantities required;
4. Incoterm: FOB, CFR, CIF;
5. Delivery Cost: It is determinated by the destination port;
6. Payment Term: PayPal; T/T; L/C.
7. Shipment: by sea, by air, by courier, by post, etc.
